Description
The 12V Motor Positive and Reverse Remote Control Receiver Board is designed to control motors in both forward and reverse directions. It is suitable for applications such as automatic doors and rolling shutter doors.
- Outputs: Two passive outputs, independent or non-lock and latch output
- Control: Dual control function (hand control and remote control)
- Learning button: Included for stop function
- Receiving sensitivity: High, with a remote control distance of 50-100m
- Relay capacity: High-capacity relays, controlling up to 10A
- Coding technology: Wireless coding, no direction interference
- Limit function: Double limit, normally open type limit function
- Operating voltage: DC 12V
- Receiving frequency: 315MHz
- Receiving sensitivity: -105dB
- Working modes: Pointing, interlocking, self-locking
- Coding type: Learning type
- Coding mode: Learning code
- Application: Controls motor forward and reverse, suitable for automatic doors and rolling shutter doors
